Dartmoor Raider 27,5 Boost 110x15 mm - front wheel

Dartmoor Raider Boost wheel - Tubeless ready

Affordable 27,5" trail/enduro tubeless-ready wheels based on Dartmoor Raider rims. Available in Boost standard or non-Boost standard. Rear wheels are equipped with Reel Boost v.2 148x12mm hub with 4 sealed bearings and reliable steel freehub with 3 pawls system. All bearings are filled with waterproof synthetic Mobil grease. Wheels come with Ride Your Way nylon rim tape and taper grip brass nipples, which are designed to achieve maximum grip without the need for thread lock. The upper part of the nipple thread is tapered inward to lock the spoke in place during the wheel building and help the spoke to stay tight also after use. Rear wheels are equipped with regular Shimano type freehubs. SRAM XD freehub is also available as a spare part. Shimano Microspline freehub is not available.

SPECIFICATION
Sizes: 27.5; 29"
Holes: 32
Rims: Raider/sleeved joint
Rear hub: Reel Boost v.2 148x12mm
Front hub: Reel Boost 110x15mm
Spokes: Pillar 2.2/2.0 black
Nipples: Pillar brass/Taper Grip black
Recommended tire range size: 2.1"-2.5"
Weight: 1026g (27.5" front); 1256g (27.5" rear); 1080g (29" front); 1305g (29" rear)

 ------------------------------------------

HUB SPECIFICATION

REEL BOOST 110x15 Disc 32 H front hub
Reliable front hub to use for Enduro, All Mountain, Freeride and Dirt Jumping. Equipped with 2 high quality sealed bearings with custom selected Mobil waterproof grease and full contact seals.
Available in: 110x15mm

SPECIFICATION
Sizes: Disc 110x15mm;
Bearings: 2 precision sealed bearings with high density grease, full contact sealings
Bearings type: 6804
Hub-shell: alu 6061-T6
Cones: alu 7075-T6, push-in (both sides)
Holes: 32H
Weight for Disc version: 199g (110x15mm)

RIM SPECIFICATION
Dedicated for wide tires (2.1”-2.5”)
Sizes: 27.5", 29”
Holes: 32H
Joint: sleeved
Outer width: 31,4mm
Inner width: 24mm
Height: 21mm
Weight: 580g (27.5”)
