Dartmoor Blackbird 29 frame BlackG (without shock)

Dartmoor Blackbird 29 frame  without shock

New version of Blackbird 29 frame is designed for the 230x65mm metric shocks and 148x12mm Boost hubs.
Enduro frame on 29" wheels. Built based on modern progressive geometry designed for 29 inch wheels with a low positioned BB relatively long front triangle and a 65º head tube angle. The simple, single pivot construction delivers a smooth, linear and more reliable suspension performance. 29" wheels provide better traction on trails and more stability in difficult terrain. Bigger wheels will be perfect for riders who prefer fast, challenging trails and longer distances. Like in 27.5" frame, the swingarm is connected to the front triangle with a super stiff 17mm axle and mounted on three Max type bearings packed with waterproof Mobil grease. 29" wheeled Blackbird frame comes with 148x12mm rear spacing Boost standard.

     Blackbird/Bluebird rear shock assembly- montáž tlumiče do rámu

     Blackbird suspension setup video - nastavení odpružení

SPECIFICATION:

• Frame size: Medium, Large, XLarge
• Wheel size: 29"
• Frame travel: 160mm;
• Recom. fork travel: 160-170mm;
• Shock size: 230x65mm;
• Shock hardware: 22.2x8mm;
• Max tire size: 29x2.5";
• Max chainring size: 34T;
• Hub size: 148x12mm (Boost);
• Post/clamp diam.: 30.9mm/34.9mm;
• Headset type: IS42/IS52;
• Weight: 3.6kg (w/o shock).
